Reactor

A filter reactor is appropriate for reactive power compensation and harmonic control systems. The filter reactor is linked with a capacitor and creates either minimal impedance or maximal impedance by utilizing the physical properties of LC resonance. It can either absorb or obstruct the harmonic voltage and current of the corresponding frequency in the power grid, thereby achieving the goal of harmonic filtering, maintaining the optimal value of the system’s power factor, and significantly enhancing the power quality of the power grid.

The CKFG Series Reactor by BaoYu Holding Technology Co., Ltd. is a High Quality solution designed for Series Reactor in Power System applications, delivering unmatched reliability in industrial and renewable energy grids. Engineered to stabilize Power Voltage and suppress harmonics, this reactor integrates Anti Harmonic technology to reduce 5th, 7th, and higher-order distortions (THDi <5%),Soft Starter Compatibility: Protects motors and drives from inrush currents, extending equipment lifespan.Voltage Stabilization: Dampens Power Voltage fluctuations caused by non-linear loads, enhancing grid reliability.Robust Construction:High-quality silicon steel cores and Class H insulation ensure  lower losses

Dry-type iron core series reactor is used in low voltage reactive power compensation cabinet and connected in series with capacitor. When there are a large number of harmonic sources such as rectifier and converter in the low-voltage grid, the high harmonics generated will seriously jeopardize the safe operation of the main transformer and other electrical equipment. After series connection of reactor and capacitor, it can effectively absorb grid harmonics, improve the voltage waveform of the system, improve the power factor of the system, and effectively inhibit the closing inrush current and operating overvoltage, effectively protect the capacitor.

The CKSG Series Reactor by Baoyu Holding Technology Co., Ltd. is a critical Series Reactor in Power System, designed to enhance grid stability and mitigate harmonic distortion in industrial and renewable energy networks. As a high-performance Reactor Electric solution, this Series Reactor suppresses harmonics (5th, 7th, and higher orders), limits inrush currents, and stabilizes voltage fluctuations in low-voltage applications (up to 690V), ensuring compliance with international standards.

When compensating for capacitive reactive power, capacitors are often affected by harmonic currents,closing inrush currents, and operating process voltages, resulting in capacitor damage and power factor reduction. Therefore, a series reactor needs to be installed at the front end of the capacitor to suppress and absorb harmonics, protect the capacitor, avoid the impact of harmonic voltage and current, improve power auality, improve system power factor, and extend the service life of the capacitor.

The hiah-voltage series reactor is mainly connected in series with the high-voltage parallel capacitor to limit the closing inrush current during the switching process of the capacitor, suppress the distortion of the grid voltage waveform, control the harmonic component flowing through the capacitor, and eliminate the damage of harmonics and overcurrent to the capacitor. in addition, some power grids or electrical equipment also connect reactors for current limiting protection to limit sudden changes in current. With the continuous development of the power arid, as an indispensable eauipment in reactive power compensation devices,hiah-voltage series reactors are increasingly widely used.
