CKSC-240/10-6 Three-Phase High-Quality High-Voltage Series Reactor
Model Meaning
Specification of CKSC-240/10-6 High - voltage series reactor
| Type | CKSC-240/10-6 |
| The Power Supply | 10kV |
| Kinds of reactance | 4.5% |
| Rated Current | 210A |
| Reactor Capacity | 240Kvar |
| Rated inductance | 3.587Mh |
| Rated insulation level | 3kV/min |
| Insulation Level | LevelB，LevelF，LevelH |
| Noise | Not Exceed50dB |
| Overload Capacity | Continuous operation within 1.35 times or less |
| Altitude | Not Beyond 2000 meters |
| Working environment temperature | From -25 ℃ to+45 ℃ |
| Relative Moisture | Not Beyond 90% |
| Working terms | No harmful gases or flammable or explosive materials around |
| Installation Situation | The surrounding environment should have good ventilation conditions, lf installed in a cabinet, ventilation equipment should be installed |
Overview of CKSC-240/10-6 High - voltage series reactor
Engineered for critical Harmonic System control, the CKSC-240/10-6 High-Voltage Series Reactor by Baoyu Holdings delivers premium Electrical Reactor Function in industrial power networks. As a robust Harmonic Filter Reactor, it suppresses harmonic distortions up to 40th order, stabilizing AC Power Voltage across 3 Phase System Voltage infrastructure. This Quality Power Reactor optimizes 3 Phase Current to Power conversion and enhances Power Factor of Electricity through advanced Reactive Power Compensation. Acting as a Voltage Reactor, it corrects imbalances while reducing Reactive Power Consumption in 3 Phase Electric grids. Its core design as a Compensation Reactor minimizes Electrical Reactive Power losses by 25%, ensuring efficient 3 Phase Output delivery. Ideal for mitigating Harmonic pollution in data centers and manufacturing plants, this Reactor in Electrical System applications guarantees voltage stability under ±15% grid fluctuations.
Integrated Circuit Protection defines the CKSC-240/10-6’s reliability. Featuring dual-mode Over Voltage and Over Current Protection + Over Voltage and Under Voltage Protection, this Reactor safeguards sensitive equipment from grid anomalies. Its low-loss magnetic core (THD < 2%) optimizes Reactive Power management in 3 Phase Power systems, while the reinforced Reactor Circuit withstands 50kA short-circuit currents. As a Harmonic Filter Reactor, it extends capacitor lifespan by 30% in Harmonic Systems. The Reactors’ Class H insulation operates at 180°C, supporting 3 Phase Power Voltage up to 480V. Key for Reactive Power Compensationprojects, it reduces Electrical Reactive Power waste by improving PF to 0.95+,this High-Voltage Series Reactor delivers 99.7% uptime in harsh environments. Deploy it for transformer inrush limitation, harmonic filtering, and robust Over Voltage defense – essential for mining operations and utility substations demanding uncompromised Quality Power Reactors.
CKSC-240/10-6 High - voltage series reactor Main Advantages
- Excellent harmonic suppression: As a high-efficiency harmonic filter reactor, it eliminates harmonic distortion in the harmonic system and ensures the original reactor function.
- Voltage stabilization: Acts as a key voltage reactor to stabilize the AC power supply voltage and three-phase power supply voltage fluctuations in the three-phase system voltage network.
-
Reactive power optimization: Through precise reactive power compensation, the power factor is improved, reactive power consumption and reactive power waste are reduced.
- Powerful circuit protection: integrated overvoltage and overcurrent protection + overvoltage and undervoltage protection, providing unparalleled circuit protection for reactor circuit applications.
- Three-phase performance: Optimize the conversion of three-phase current to power to achieve consistent three-phase output in three-phase electricity/three-phase power systems.
- System Reliability: Designed as a premium power reactor, it ensures reliable reactor electrical system operation and extends equipment life.
- Energy-saving design: The compensation reactor can reduce reactive power loss by 30%, which has been verified in the high-voltage series reactor test.
- Grid Resilience: As an industrial-grade reactor, it can protect the reactor power infrastructure from harmonic pollution and voltage instability.
Core Working Principle of CKSC-240/10-6 High - voltage series reactor
1. Harmonic filtering core technology
CKSC-240/10-6 is a precision harmonic filter reactor that uses multi-layer silicon steel laminations to produce high impedance to harmonic frequencies (5-40th) in harmonic systems. The reactor function suppresses distortion by blocking harmonic currents from propagating in the reactor circuit, while achieving clean three-phase current-power conversion. The voltage reactor is designed to stabilize AC power supply voltage fluctuations within ±1%, ensuring the performance of high-quality power reactors. By integrating flux control technology, this reactor can reduce the total harmonic distortion (THDi) of harmonics in the three-phase system voltage infrastructure by 35% in the power system, effectively protecting sensitive equipment from overheating caused by harmonics. Its three-phase electrical compatibility makes it an ideal choice for industrial three-phase power grids that require strong harmonic suppression measures.
2. Reactive power compensation mechanism
This compensation reactor is designed with an optimized air gap to manage reactive power in three-phase voltage systems. By inducing controlled inductive reactance, it can offset capacitive reactive power consumption, thereby improving the power factor of the power supply to above 0.95. As a high-voltage series reactor, it is able to store/output reactive power during voltage peaks/valleys in the three-phase output cycle, thereby achieving dynamic reactive power compensation. The high-temperature resistant windings (H-class insulation) of the reactor maintain a stable impedance during overvoltage and undervoltage protection events, thereby reducing reactive power losses by 28%. The core function of this reactor works in conjunction with the capacitor bank to regulate reactive power, making it an indispensable component in reactive power compensation in mining and utility substations.
3. Multi-layer circuit protection system
The reactor uses graded insulation and magnetic flux density monitoring technology to achieve overvoltage and overcurrent protection. In the event of a grid fault, its reactor circuit can instantly increase impedance by 300%, limiting the short-circuit current to less than 50kA, thereby acting as a critical circuit protection barrier. At the same time, the harmonic filter reactor function can trigger the harmonic damping coil to suppress transient voltages exceeding 125% of the nominal three-phase power supply voltage. As high-quality power reactors, they provide dual overvoltage and undervoltage protection through embedded voltage sensors. When the AC power supply voltage deviation exceeds ±15%, the sensor will start magnetic saturation control. The electrical protection measures of the reactor can extend the service life of the capacitor by 40%, while ensuring a stable three-phase current-to-power ratio even during lightning strikes or switching surges.
Size of CKSC-240/10-6 High - voltage series reactor
| Model | A | L | H | B | W |
| CKSC-240/10-6 Reactor | 660mm | 1330mm | 1126mm | 660mm | 740mm |
